P2.5 Outdoor LED Display Module

P2.5 Outdoor LED Display Module

Pixel pitch: P2.5 (2.5mm)

Recommended: Premium shop signage, Roadside branding, High-detail outdoor digital signage, Showroom facade display

Key Features

  • Standard Size: 320×160 mm universal outdoor LED module.
  • Lightweight Design: Supports easier installation and reduced structural load with proper cabinet planning.
  • High-Quality Lamp Beads: Durable SMD1921 LEDs for stable long-hour operation.
  • Enhanced Reliability: Optimized power and signal workflow supports High clarity outdoor visuals, Daylight visibility planning, Weatherproof cabinet integration, Smooth playback (controller dependent), Good for close viewing content.
  • Excellent Visual Experience: 5000 : 1 and ≥ 95% for clear viewing performance.
  • Good Compatibility: Suitable for Premium signage & branding.
  • Installation Friendly: Supports practical mapping, calibration, and long-term maintenance workflow.
  • High Refresh Rate: Supports up to 3840 Hz (Standard) / 7680 Hz (Optional) for camera-friendly performance.

High-clarity outdoor module for close-to-mid viewing—premium signage, showroom facade and roadside brand screens.

Detailed Overview

P2.5 Outdoor LED Display Module is suitable for outdoor visibility where weather conditions, installation safety, and content readability from distance are critical. Final planning should confirm height, viewing angle, and stable power routing.

What you get from us

  • - BOQ-based quotation and model recommendation
  • - Controller configuration and calibration guidance
  • - Power planning and installation support
  • - After-sales support and spare planning
ParameterValue
Pixel PitchP2.5 (2.5mm)
LED TypeSMD1921
Module Resolution (W×H)128×64 = 8,192 pixels
Pixel Density160,000 dots/m²
Module Size (W×H)320×160 mm
Module WeightProject dependent
HUB TypeHUB75
Brightness5500 cd/m²
Color Temperature3200 K - 9300 K adjustable
Viewing Angle (H/V)140° / 140°
Brightness / Color Uniformity≥ 95%
Contrast Ratio5000 : 1
Max Power Consumption700 W/m²
Typical Power Consumption260 W/m²
Input VoltageAC 90-132 V / AC 186-264 V (47-63 Hz)
Frame Frequency60 Hz
Refresh Rate3840 Hz (Standard) / 7680 Hz (Optional)
Processing Depth14 - 16 Bit
Video Support2K / 4K UHD
Life Span100,000 Hours
Operating Temp / Humidity-20°C to +50°C / 10% - 90% RH
Storage Temp / Humidity-20°C to +50°C / 10% - 80% RH
CertificationsBIS / CE / CB / RoHS / EAC
EnvironmentOutdoor
Use CasePremium signage & branding
